Meiflow Top S MC, DN25, With Wilo Yonos Pico Plus 25/1-6 M66931.10WI Mixed Circuit Pump Group
In-stock, Contact forĀ Quote - Live ChatĀ /Ā 01985 850982Ā
Ideal for surface-mounted manifold heating circuits up to 70 kW. Includes recirculating pump with angled connector and two ball valves equipped with a manually adjustable backflow limiter on the return line side. Features an integrated sensor mounting in the flow line and two contact thermometers in the ball valve handle with a range of 0-120 Ā°C. Also includes a 3-way T-mixer with an adjustable bypass, EPP insulation, and a wall bracket. Flow and return line sides can be easily swapped.
Meiflow Top S MC pump groups
With Wilo Yonos PICO Plus 25/1-6
Connection (uppermost) DN25 /Ā "G 1" F
Technical Data Meiflow Top S MC
| Specifications | DN 25 |
| Dimensions HxWxD [mm] | 421 x 249 x 220 |
| Upper connections | G 1" F |
| Lower connection | G 1Ā 1ā2" M |
| Axial distance [mm] | 125 |
| Max. operating temperature [Ā°C] | 110* |
| Permissible positive operating pressure [PN] | 6 |
| Thermometers [Ā°C] | 0 - 120 |
| Components made of | Steel, brass, EPP insulation |
| Sealing materials | PTFE, EPDM |
| Installed length of pump [mm] | 180 |
| Kvs value [m3/h] | 5.8 |
| Sensor mounting | M10x1 |
