Hexonic/Secespol heat exchanger SCP-LC110- 40 Plates - 2' inch - 2 x Font / 2 x Back For 200kW
Call to check stock:Ā Ā Live ChatĀ /Ā 01985 850982Ā - 1 last left in Stock (03/07/23)
Hexonic/Secespol heat exchanger SCP-LC110- 40-2'
40 Plate
Rated for upto 200kW
SECESPOL
Type LC110-40-2"
Code 0406-0163
Serial - 22L300050592-039-003
Description
L-line heat exchangers are copper-brazed exchangers dedicated to standard heating or cooling installations of liquid-liquid type. The special corrugation pattern of the plates ensures a compromise between low flow resistance and high heat exchange efficiency. Vacuum furnace technology ensures integrity and permanent fusion of plates which enables the unit to withstand high-pressure and high-temperature conditions.
Technical specification
| Article | 0206-0274 |
| Producer | HEXONIC / Secespol |
| Series | LC110 |
| Number of plates | 40 |
| Size | 258 x 466 |
| Number of stages | Single stage (4 connection) |
| Number of connections | 2 x Front / 2 x BackĀ |
| Connection type S1; S2 | G2ā |
| Connection type S3; S4 | G2ā |
Ā
Original: $1,661.51
-70%$1,661.51
$498.45Product Information
