CR3P-282301 - Pack c/w R37-HW, 2 x DS222P, 2 x CM3 & WC2 - 3 Zone Heating Control Packs

Direct from EPH - Delivery Lead time 4-5 Working days :  Live Chat / 01985 850982



CM3 - Heating-Cooling Room Thermostat with Light

The room temperature is measured using an internal gas-filled sensor and then compared with the set point. When the set point is above the room temperature, there is a call for heat and the thermostat switches out on terminal 2. When the set point is below the room temperature, there is no call for heat and the thermostat switches out on terminal 1.

• Product Code - CM3
• Temperature Range -  5 ... 35˚C
• Contact -  SPDT
• Lockable Range -  Yes
• Heat Anticipator -  Yes

WC2 -  12 Way Wiring Centre – Block Connector Strip

Wiring centres for use in central heating systems.

DS222P DETACH PRO - 2 Port 22mm Motorised Valve

The DS222P DETACH PRO valve is specifically designed for use in domestic applications only.

It is not designed for use in commercial or industrial applications such as schools, nursing homes or hotels where large commercial pump sets are fitted.

Warranty will be void if a valve is fitted in any application other than domestic. Please note we have a full range of commercial and industrial valves to suit every application.

• DS222P
• CONNECTION TYPE - 22mm compression
• FLOW RATE 4.6 kvs
• MAX. CLOSE OFF PRESSURE - 1.0 bar

Switch Rating	11(3)A 230Vac
Max Ambient Temp	50˚C
Max Fluid Temp	88˚C



Download

• DS222P Datasheet
