C00P-232A00 - Pack c/w 2 x V228P & 2 x CP4M - 2 Zone Combi Zoning Control Packs

Direct from EPH - Delivery Lead time 4-5 Working days :  Live Chat / 01985 850982



The EPH 2 zone wireless combi control pack gives you everything you need in one box to create two heating zones. Ideally suited to combi boilers and properties where hard wiring of the thermostats is difficult, this pack gives you the flexibility to have independent control of your heating in two separate zones such as upstairs and downstairs, improving cost efficiency.

Includes

• 2 x V228P - 2 Port Valve – 28mm compression 6.8 kvs 0.6 bar
• 2 x CP4M (COMBIPACK4) – OpenTherm® Programmable RF Thermostat



CP4M – OpenTherm® Mains Operated Programmable

This digital programmable room thermostat is suitable for controlling 1 heating zone. It features OpenTherm®, Optimum Start, TPI and On/Off control modes.

The thermostat is mounted on a 6-pin industry standard backplate.

Boiler Plus Compliant.

Technical Data

V228P - 2 Port 28mm Compression Motorised Valve

2 port compression motorised valves with detachable actuator, detachable cable and power on light. These motorised valves are the perfect solution for zoning your hot water or central heating circuits.

• V228P
• CONNECTION TYPE - 28mm compression
• FLOW RATE 6.8 kvs
• MAX. CLOSE OFF PRESSURE - 0.6 bar

Switch Rating	11(3)A 230Vac
Max Ambient Temp	50˚C
Max Fluid Temp	88˚C



Download

• V228P Datasheet
